COPY OF LTC7068数据手册和产品信息

发布时间: 2024-11-11 09:18:49
来源: analog.com
LTC7068 Typical Application Diagram 1
LTC7068 Block Diagram
LTC7068 Pin Configuration
.
特性
  • 150V Maximum Input Voltage Independent of IC Supply Voltage V CC
  • 6V to 14V V CC and Bottom Gate Driver Voltage
  • 4V to 14V Top Gate Driver Voltage
  • 1.3Ω Pull-Down, 1.6Ω Pull-Up
  • Adaptive Shoot-Through Protection
  • Three-State PWM Input with Enable Pin
  • V CC UVLO and Floating Supply UVLO
  • Drives Dual N-Channel MOSFETs
  • Available in Thermally Enhanced 10-LEAD Mini Small Outline Package (MSOP)
.

The LTC7068 is a half-bridge dual N-Channel MOSFET gate driver that operates at up to 150V input voltage and features a supply-independent three-state pulse width modulation (PWM) input logic.

The strong 1.3Ω pull-down and 1.6Ω pull-up drive capability can drive large gate capacitances of high voltage MOSFETs with short transition times in high switching frequency applications. The adaptive shoott-through protection is designed for optimized efficiency and MOSFET cross-conduction protection.

The LTC7068 contains undervoltage lockout (UVLO) circuits on both the V CC supply and floating driver supply that turn off the external MOSFETs when activated.

Applications

  • Industrial Power Systems
  • Half-bridge DC/DC Converters
  • Telecommunication Power Systems
.
